轴承型号 外型尺寸（毫米） Boundary Dimensions(mm) 基本额定负荷（千牛） 极限转速（转/分） 重量
Bearing Deignations Basic Load Rating Limiting Speed （千克）
(KN) ( r/min) Weight
(kg)
新标准 旧标准 d D B FW 动 态 静 态 润滑剂 Lubricant
New Old Dynamic Static
Standard Standard Cr Cor 脂 Grease 油 Oil
FC3045120 672830K 150 225 120 169 639 746 2200 2800 16
FC3042120 150 210 120 166 603 779 2200 2890 12.5
FC3044120 672930K 150 220 120 167 639 764 2100 2700 15.6
FC3044150 150 220 150 168 701 1049 2100 2780 19.4
FC3045120 672730K 150 225 120 169 670 880 2000 2600 16
FC3045150 150 220 150 169 779 1090 2000 2600 20
FC3046130 150 230 130 174 657 937 2000 2600 19.8
FC3046150 150 230 150 700 968 2000 2600 23
FC3046156 672730 150 230 156 174 750 990 2000 2600 24
FC3246130 160 230 130 180 655 710 2000 2600 16.8
FC3246168 160 230 168 177 905 1260 2000 2600 23
FC3248124 672732K 160 240 124 183 680 823 1900 2400 19.6
DC3248124 160 240 124 183 636 968 1900 2400 17.6
FC3248168 672732 160 240 168 183 900 1370 1900 2400 26.1
FC3446120 170 230 120 187 588 981 1900 2400 14.1
FC3446130 170 230 130 188 603 918 1900 2400 15.6
FC3446180 170 230 180 186 909 1272 1900 2400 21.1
FC3448130 170 240 130 190 821 1210 1800 2300 18.7
FC3450150 170 250 150 192 693 1073 1900 2400 25.2
FC3450168 170 250 168 192 941 1432 1890 2270 28.2
FC3450170 672734 170 250 170 192 941 1432 1800 2200 28.6
FC3451180 170 255 180 193 1020 1540 1700 200 32.5
FC3452120 170 260 120 195 782 1095 1800 2200 23
FC3452150 170 260 150 195 804 1128 1800 2200 28
FC3452170 170 260 170 195 940 1310 1800 2200 31
FC3452192 170 260 192 195 989 1400 1700 2000 36.5
FC3452225 170 260 225 196 1400 1760 1800 2200 43.5
FC3650156 672736K 180 250 156 198 860 1300 1800 2200 28.7
FC3652120 180 260 120 202 707 990 1800 2200 20.2
FC3652124 180 260 124 202 707 990 1800 2200 20.7
FC3652156 180 260 156 198 1800 2200 28.7
FC3652160 180 260 160 202 1090 1580 1800 2200 28.8
FC3652168 672736 180 260 168 202 993 1320 1800 2200 28.8
FC3653180 180 265 180 206 1040 1660 1700 2000 34
FC3656180 180 280 124 206 1170 1872 1700 2000 40.4
FC3852124 190 260 124 1700 2000 19.5
FC3852168 190 260 168 212 909 1271 1700 2000 26.1
FC3853124 190 265 124 213 1710 2000 21.2
FC3854166 190 270 166 212 940 1540 1700 2000 30.5
FC3854168 672738K 190 270 168 212 940 1542 1700 2000 31
FC3854200 672738 190 270 200 212 1210 1762 1700 2000 36.3
FC3856200 190 280 200 214 1513 2190 1700 2000 41.5
FC4054170 200 270 170 222 965 1370 1600 1900 28.5
FC4056170 200 280 170 222 1160 1560 1600 1900 33.5
FC4056188 672740K 200 280 188 222 1230 1700 1600 1900 36.1
FC4056200 200 280 200 222 1283 1796 1600 1900 37.5
FC4058130 200 290 130 226 856 1198 1600 1900 27.6
FC4058192 672740 200 290 192 226 1240 1984 1600 1900 41.7
FC4058202 200 290 202 226 1240 1984 1600 1900 43.4
FC4062230 200 310 230 229 1589 2354 1600 1900 64.5
FC4156190 205 280 190 1260 1790 1600 1900 35.6
FC4258192 210 290 192 234 1140 1824 1500 1800 38.2
FC4260170 210 300 170 234 1140 1830 1500 1800 38.1
FC4260210 210 300 210 234 1366 2006 1500 1800 47.6
FC4460190 220 300 190 240 1400 1700 39.5
FC4460192 672944 220 300 192 242 1400 1700 40
FC4462190 220 310 190 246 1289 1885 1400 1700 45.3
FC4462192 672744 220 310 192 246 1298 1941 1400 1700 46
FC4462225 220 310 225 245 1630 2240 1400 1700 54.5
FC4462192 672844 220320 192 1400 1700 52
FC4464210 220 320 210 248 1460 2122 1400 1700 55.1
FC4468192 672744K 220 340 192 246 1398 1972 1400 1700 64.5
FC4468210 672844K 220 340 210 1400 1974 1400 1700 71
FC4666206 672744 230 330 206 260 1410 2060 1300 1600 56.1
FC4668260 230 340 260 261 1830 2930 1300 1600 80.8
FC4673250 230 365 250 266 1804 2660 1300 1600 100
FC4866180 240 330 180 265 1430 1930 1300 1600 50
FC4866220 672748 240 330 220 264 1460 2230 1300 1600 56
FC4868192 672748K 240 340 192 268 1497 2154 1300 1600 56.5
FC4872220 240 360 220 272 1753 2687 1200 1500 77.8
FC5068170 250 340 170 274 1220 1950 1200 1500 44
FC5070220 672750 250 350 220 278 1693 2544 1200 1500 65.3
FC5070230 250 350 230 278 1200 1500 69
FC5072220 672750K 250 360 220 282 1700 2650 1100 1400 67
FC5274200 260 370 200 292 1610 2556 1100 1400 68.5
FC5274220 672752 260 370 220 292 1763 2649 1100 1400 76
FC5274230 260 370 230 292 1763 2949 1100 1400 79
FC5276220 260 380 220 292 1100 1400 85
FC5276280 672852 260 380 280 295 1100 1400 107.5
FC5280290 260 400 290 296 2550 3825 1100 1400 134
FC5374234 265 370 234 300 1860 2760 1000 1300 80
FC5476230 672754 270 380 230 298 1843 2814 1000 1300 81
FC5476275 270 380 275 298 1000 1300 98.3
FC5478220 270 390 220 306 1850 3960 1000 1300 86.3
FC5478240 270 390 240 298 2236 3510 1000 1300 81
FC5480220 672854 270 400 220 305 1000 1300 96
FC567200 672956 280 375 200 307 1000 1300 62.2
FC5676192 280 380 192 310 1000 1300 63.4
FC5678220 672756 280 390 220 312 1828 3510 1000 1300 80.8
FC5678240 280 390 240 312 1844 3340 1000 1300 88.6
FC5678275 280 390 275 308 2226 3972 1000 1300 101.3
FC5682300 672856 280 410 300 2310 3510 1000 1300 141
FC5684280 280 420 280 318 1000 1300 138
FC5684300 280 420 300 319 2708 4514 1000 1300 147
FC5878234 290 390 234 320 1780 3386 950 1200 80
FC5882240 672758 290 410 240 320 2470 3638 950 1200 101
FC5884300 290 420 300 327 2570 4618 950 1200 139
FC6084218 672760K 300 420 218 332 2020 3960 900 1100 94.2
FC6084240 672760 300 420 240 330 2200 3360 900 1100 104
FC6084300 300 420 300 330 2476 4418 900 1100 130
FC6286240 310 430 240 344 2040 3634 900 1100 106.6
FC6488240 320 440 240 351 2172 3163 850 100 122
FC6488300 320 440 300 351 2196 3355 850 1000 129
FC6490180 320 450 180 355 2198 3360 850 1000 90.6
FC6490240 320 450 240 355 2196 3380 850 1000 120.6
FC6492300 672764k 320 460 300 357 2600 4060 850 1000 157
FC6492340 320 460 340 354 2600 4200 850 1000 183
FC6496290 320 480 290 364 2700 4500 800 1000 186
FC6686230 330 430 230 358 1830 3560 800 1000 87.4
FC6692340 672766 330 460 340 365 2800 4440 800 1000 175
FC6890250 340 450 250 364 2400 4100 800 1000 108.6
FC6890250A 340 450 250 369 2130 4860 800 1000 109
FC6892260 672768 340 460 260 370 2400 3780 800 1000 126
FC6896280 672868 340 480 280 374 3120 4760 750 950 160.8
FC6896350 340 480 350 378 3140 5080 750 950 201
FC70100380 672770 350 500 380 389 3300 5340 700 900 242
FC7296290 360 480 290 394 2600 4180 700 900 146
FC72104380 360 520 380 405 700 900 266
FC7496250 370 480 250 401 2210 4000 117
FC74108400 370 540 400 415 4180 6540 296
FC76100290 380 500 290 414 2700 4800 148
FC76104290 380 520 290 418 3000 5310 183
FC76108340 380 540 340 424 3800 6760 250
FC76108400 672776 380 540 400 422 4200 6820 294
FC78102290 672878 390 510 290 424 2800 4880 160
FC80104250 400 520 250 432 2348 4686 138
FC80110300 672780 400 550 300 441 3286 5988 223
FC80112410 400 560 410 445 4769 7586 315
FC8012350 400 600 350 455 356
FC84120280 420 560 280 457 3010 5786 192
FC84120440 420 600 440 470 4962 9101 400
FC88124450 440 620 450 487 5246 9510 440
FC88132340 440 660 340 492 5800 9700 430
FC92124400 460 620 400 506 4286 8974 346
FC92120470 460 650 470 509 6460 115000 510
FC96136500 480 680 500 532 6860 12000 605
FC78110400 672778 390 550 400
FC74104400 672774 370 520 400
FC72102370 672772 360 510 370
FC92130424 672792 460 650 424 445
FC100134450 500 670 450 446
FC100134225 6728\500 500 670 225 441
FC166216710 6728\830 830 1080 710 1901
FC190260425 6727\950 950 1300 425 3523
FCD3042120 FCDP3042120 150 210 120 166 603 965 12.5
FCD3652168 180 260 168 202 993 1320 29
FCD4058192 200 290 192 226 1240 1984 42
FCD4062230 200 310 230 229 1600 2360 64.5
FCD4260210 210 300 210 234 1366 2006 47.6
FCD4466230 220 330 230 249 1460 2122 68.5
FCD4668260 230 340 260 261 1830 2930 80.8
FCD5070220 250 350 220 27 1693 2554 67
FCD5271260 260 355 260 286 86
FCD5272204 260 360 204 287 1660 2240 64.5
FCD5276280 260 380 280 294 2197 3125 108
FCD5678220 280 390 220 312 2000 3100 83.6
FCD5680285 280 400 285 316 2650 3900 120
FCD5682300 280 410 300 313 2310 3510 141
FCD5882240 290 410 240 320 2470 3630 101
FCD5884300 290 420 300 327 2569 4609 138
FCD6080300 300 400 300 328 105
FCD6084240 300 420 240 332 2193 3353 104
FCD6084300 FCDP6084300 300 420 300 332 2539 4003 130
FCD6286240 310 430 240 345 106.6
FCD6488240 320 440 240 351 2169 3157 128
FCD6490240 320 450 240 355 2193 3353 120
FCD6492300 320 460 300 357 2567 4058 157
FCD6492340 320 460 340 354 2600 4200 183.3
FCD6492340 320 460 340 360 2600 4200 183
FCD6496290 320 480 290 364 2700 4500 186
FCD6496350 FCDP6496350 320 480 350 364 3267 4536 231
FCD6692340 FCDP6692340 330 460 340 365
FCD6890250 340 450 250 364 2400 4100 108.6
FCD6892260 340 460 260 37 2395 4072 125
FCD6896280 340 480 280 378 3120 4760 161
FCD6896350 FCDP6896350 340 480 350 378 3138 5021 201
FCD100144530 FCDP100144530 500 720 530 568
FCD106156570 FCDP106156570 530 780 570 601
FCD110148510 FCDP110148510 550 740 510 600
FCD112164630 FCDP112164630 560 820 630 625
FCD114163594 FCDP114163594 570 815 594 628
FCD120164575 FCDP120164575 600 820 575 660
FCD120174640 FCDP1201174640 600 870 640 682
FCD126180670 FCDP126180670 630 900 670 698
FCD130184670 FCDP130184670 650 920 670 723
FCD134190700 FCDP134190700 670 950 700 750
FCD138196715 FCDP138196715 690 980 715 767.5
FCD140186620 FCDP140186620 700 930 620 763
FCD142200715 FCDP142200715 710 1000 715 787.5
FCD146192620 FCDP146192620 730 960 620 790
FCD150200670 FCDP150200670 750 1000 670 813
FCD160216700 FCDP160216700 800 1080 700 878 14000 52200 1859
FCD160230850 FCDP160230850 800 1150 850 905
FCD170230840 FCDP170230840 850 1150 840 928
FCD180244840 FCDP182744840 900 1220 840 989
FCD1902721000 FCDP19022721000 950 1360 1000 1058
FCD200272800 FCDP200272800 1000 1360 800 1084
FCD2123001120 FCDP2123001120 1060 1500 1120 1165
FCD222296980 FCDP222296980 1110 1480 980 1210
FCD2243161150 FCDP2243161150 1120 1580 1150 1240
FCD5678275 FCD5684275 FC5882240
FCD70104300 FCD72102370 FCD72104380
FCD74104380 FCD74108380 FCD76108380
FCD76108400 FCDP78108320 FCDP78110310
FCD80110300 FCD80112410 FCD80118440
FCDP82112400 FCDP82120440 FCD84116260
FCD84116320 FCDP84120440 FCD84124400
FCDP88124450 FCD88130355 FCD88126450
FCDP90118300 FCDP92130424 FCDP92130470
FCDP96130450 FCDP96136420 FCDP96136500
FCD100130260 FCDP100134450 FCD100136405
FCDP100136450 FCD100142480 FCD100144400
FCD100144530 FCDP102136500 FCD102146520
FCDP102152550 FCDP106152520 FCD106156500
FCDP106156570 FCDP110148510 FCDP110160520
FCD110160560 FCDP120164575 FCDP120174540
FCDP120174640 FCDP122164430 FCDP130180650
FCDP130184670 FCD132164440 FCD132176450
FCDP136188600 FCDP136196640 FCDP138196715
FCDP138196750 FCDP140186620 FCDP140196700
FCDP142200715 FCDP146188500 FCD146192620
FCDP146206750 FCD150200500 FCDP150200670
FCDP156214780 FCDP160216700 FCDP160230850
FCDP164226800 FCDP170230840 FCDP170236850
FCDP170244900 FCDP180244840 FCDP180256930
