广东钢球厂HRT防锈滚珠0.85mmG10高精密SUS440C 产品标签： 不锈钢珠 钢珠 1588mm不锈钢珠 订货量（个） 价格 30000 - 99999 0.04元/ 个 ≥100000 0.04元/ 个 发 货 期：5天内发货 所 在 地：广东 中山手 详细信息品牌： HRT 型号： SUS440C 加工定制： 是 是否标准件： 标准件 样品或现货： 现货 是否进口： 非进口 类型： 钢球 用途： 轴承、电气、设备、仪器、仪表 材质： 不锈钢 尺寸： 0.85mm 红润泰钢球0.85mmG10高精密SUS440C材质不锈钢珠 供中山钢球厂0.85mm高精密SUS440C材质不锈钢珠 1) 材料：不锈钢440C; 2) 直径:0.85mm; 3) 级别:G5~ G1000; 4) 证书:ISO-9001,TS-16949,ISO14001; 5) 硬度:≧ HRC 55. 红润泰钢球0.85mmG10高精密SUS440C材质不锈钢珠特性：具有一定耐磨性及抗腐蚀性，硬度较高，其价格是不锈钢球中较低的一类,适用于对不锈钢普通要求的工作环境中。 红润泰钢球0.85mmG10高精密SUS440C材质不锈钢珠应用：适用于各类精密机械、轴承、电气、设备、仪器、仪表、交通运输工具、家用电器等。多用于制造耐大气、水蒸气、水及氧化性酸腐蚀的零部件。 440C不锈钢球 简介 440C不锈钢球硬度很高，对淡水，蒸汽，原油，汽油，酒精，食品，血液和汗水有很好的耐腐蚀能力。除此之外，这类球磁性强，带磁时效高。 世界各国牌号 AISI 440C, DINX105 CR Mo17, JIS SUS 440C, Z100CD17 Wks 1.4125 规格 0.5mm to 50.8mm 等级 G10/G25/G50/G100/G200/G500/G1000 硬度 HRC 58-62 特性 耐磨耐腐蚀性好，硬度比420不锈钢高 用途 精密轴承，耐磨轴承，特殊阀门，传送带，传送轴，笔等。应用领域有食品业，医疗器材，速接联轴节，炼油设备 化学成分 C 0.95-1.20% Cr 16-18% Si 1.0% Max Mn 1.0% Max P 0.04% Max S 0.03% Max Mo 0.75% Max 机械性能 抗张强度- 285,000psi 抗屈强度- 275,000psi 密度- 7.67g/cc Stainless Steel AISI 440C General Information These balls give maximum hardness with good corrosion resistance to fresh water, steam, crude oil, gasoline, alcohol, food environment, blood and perspiration. In addition this material is ferro-magnetic and makes a fair permanent magnet. Balls are deep freeze stabilized after heat treatment. International Equivalents AISI 440C, DINX105 CR Mo17, JIS SUS 440C, Z100CD17 Wks 1.4125 Size Range 0.5mm to 50.8mm Grade Available G10/G25/G50/G100/G200/G500/G1000 Hardness HRC 58-62 Feature Good wear-resisting property and corrosion resistance, with higher hardness than AISI420. Applications Precision bearings, anti-friction bearings, special valves, conveyor belts and rollers, ballpoint pens. They are used in foodstuff, medical instruments, quick couplings, recirculating ball bearings, knotting devices, oil refinery devices. Material Composition C 0.95-1.20% Cr 16-18% Si 1.0% Max Mn 1.0% Max P 0.04% Max S 0.03% Max Mo 0.75% Max Mechanical Properties Tensile Strength- 285,000psi Yield Strength- 275,000psi Density- 7.67g/cc Ball　Diameter balls（kg） kgs per 1000 pcs No.of balls per kg type of bearings to which the ball is applied 时 inch 毫米 mm - 0.8000 2.00209 478470 1000082,100009/1.5,106009/1.5 - 1.0000 0.00408 245100 100008/2.5,1000083,2000083,1000092,95 (45)1060092,8001/1.5,770083 - 1.2000 0.00705 141840 96,906072,906092 - 1.3000 0.00893 111980 100084,2000084,1000093,62,106009/2.5,1060093, 80013,8060023,60073. 1820093,1830093,2106083,2006083,1080093,906093,3836093. - 1.4500 0.0124 80645 1060084 1/16 1.5875 0.016 62350 23,53,1000085,970092(970052),970093(970053), 970095(970055)640063 740063,136023,6023,906073,2830085,1080085 - 1.7500 0.0218 45871 1060085,1830085 - 2.0000 0.0326 30700 1000086,1000087,1000088,1000801,2000086, 1000094,1000095,7000807,55. 430078(2-002),640095,78075,1060089,106094, 1060095,1210801,7060015. 80014,380075,2830086,1106094,1006095,1006094,516053. 3/32 2.3812 0.055 18182 24,1000089,1000096,1380096,1380096,8060026, 8060034,8060035,6024,106096. 1006096,3106095,606016,7008903,906076,1830096,900803. - 2.5000 0.0637 15698 2060088 - 3.0000 0.110 9091 1000097,1820097. 1/8 3.1750 0.131 7634 25,16,34,1000098,1000099,1000806,1000807,1000808, 900903,900904.1000902,900805,970700,900706,900808, 900809,900810,1026,1027, 971077(971067),981075(981065),981077(981067),6073(6003). 980075(980055),980065,980077,6025,106034(76004),1080099, 60074(60064),80075,500066,526055,1008098,106025,22706k(706), 900907,900912,1740808,640075(640065),501065,1018,1035 - 3.5000 0.175 5717 1380099,1000810,7900812 5/32 3.9688 0.255 3922 17,18,19,35,26,27,28,56,66,86,89,1000900,1000901,1000903,780065 520026,530018k,530018k1,3180018,180027,7900813,980079, 980085,1029,981028,981077,(981067),7426815k(7130815).6017,6018, 6026,106018,136026,36017,36018,506057,536057,1008096, 796906(836906),796905(636905),796904(2-605),796705(2-606). 3/16 4.7625 0.441 2268 29,10009048,7000101,7000102,100,101,102, 102,200,901,690079(690069) 280701,(80701),80801，980811k，180102， 980087（980067), 80907)980906)，981078(981068), 6027,6102,6078(6008), 800620(6012),6076(6006),106028, 36019,36027,36028,36029,36100,36102,46100,46101,256500, 7426815(7710815),1200,1201,8100,8101,8102,8103. - 5.0000 0.510 1961 1000904,1000905,1000906,540822,7000910,700, 15/46 5.9531 0.860 1163 200,201,202,80902,180700,60902,6200,6202, 26202,776901,406900(2-610), 36200,46200,36202,46202,15604(2-601),3056202k. 1/4 6.3500 1.04 962 104,300,105,1000908,7000106,7000107,8107, 7000108,7000109,980704, 980705, 709,8203,704(100704),330078, 330088,1204,1301,1302, 1503,6104, 6703(6017), 1036909,688808(688908), 3056203,776701(676701), 7426824(7936824)98906(98206) 17/64 6.7469 1.25 800 203,301 9/32 7.1438 1.49 671 203,106,300,7000110,7000111,8108,700112, 7000113,20703,710,970705,8109, 970711,180205,180504,1205,1303,8110,1304,1504, 1505,1600,1601,8204,1602,1970819, 6203,26203,36203,198905k(108905),46203,3056204, 3056205,3756205,1136820, 688708,606925(3-615),106930(3-616). 5/16 7.9375 2.04 490 204,205,301,302,107,708925,108,7000114, 970205,940705,8000205(705),80905, 980700,530202(30804),180506,8205,1740817, 1206,1207,1506,1603,8206,6204, 6704(6020),26204,26205,116205,36204,46204,36205, 46205,3056304, 3086304,986711,688911,588911,776801. 3/8 9.5250 3.52 284 206,303,304,1000916,1000917,8116,905,20803,530206, 520806,140806,8117,1970826, 520206,1209,1210,1306,8207,1507,1508,1509,1510, 26704,8305,26704k(326704), 36206,688713(9688213),8113,8114,8115
